| Place of Origin: | China |
|---|---|
| Brand Name: | SFFILTECH |
| Certification: | CE |
| Minimum Order Quantity: | 1 set |
| Packaging Details: | wooden case |
| Delivery Time: | 20-30 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs per month |
| Name: | High Pressure Filter Housing | Material: | SS304,316L,carbon Steel |
|---|---|---|---|
| Height: | 40"or60"(1016mm) | Surface Treatment: | Matt |
| Filter Cartridge Size: | Diameter 6"(152mm) | Seal Type: | O Type Ring |
| High Light: | water filter cartridge housing,industrial water filter housing |
||
Plastic Industrial Cartridge High Pressure Security Filter Housing
Security Filter Housing Features:
Large flow filter shell through professional design,can be achieved in a compact space greater flow.
Can be perfectly matched to install 3M,PALL,Parker,Graver,Horizon...And other domestic brand of filter cartridge.
Automatic welding seam welding technology,weld strong and beautiful.
The open cover structure adopts quick flange,which is easy maintenance and quick to replace the filter element.
The equipment has high strength and taper stainless steel central rod,that can be conveniently and accurately installed,and the filter element is prevented from deforming.
Security Filter Housing Technical Parameters:
Filter material:SS304,316L,carbon steel
Filter cartridge size:diameter 6"(152mm);
height:40"or60"(1016mm)
Seal type:O Type Ring
Surface treatment:Matt
Filter accuracy:1,3,5,10,20,30,50,70,100um
Security Filter Housing Selection Data Sheets:
